CAPACITY :
650 to 1300 L

MONOBLOC
GN 2/1 CABINETS

OUR PROFESSIONAL REFRIGERATION SOLUTIONS

"EcoStar Plus" range
​

  • R290 fluid

  • From 650 to 1300 liters

  • Monobloc with embossed walls GN 2/1

  • Available in A class

"Fristar Plus" range
​

  • R290 fluid

  • From 650 to 1300 liters

  • Monobloc with slides for GN 2/1 grids

  • Stainless steel or white laquered steel finish

RANGE DESCRIPTION

• GN 2/1 tray format, maximum weight per tray: 60 kg • Exterior fully made of AISI 304 18/10 stainless steel • Interior fully made of AISI 304 18/10 stainless steel • Rails pressed into the walls, 55 mm spacing, 24 levels • Access through a door • Self-closing door • Key lock • Automatic lighting upon door opening • Standard stainless steel feet with 360° weld, adjustable from 149 mm to 209 mm • Insulation with injected polyurethane foam, 80 mm thick, foam density: 42 kg/m³, CFC, HFC, and HCFC-free • Electronic control with digital display, automatic backup, visual alarm, HACCP alarms • Automatic defrost, hot gas defrost for low-temperature models • Hermetic monobloc air-cooled refrigeration unit (for 43 °C ambient) • Built-in ventilated evaporator with anti-corrosion treatment • Refrigerant R290 (propane) • Waterproof control panel • Visual alarm indicators

RANGE DESCRIPTION

• GN 2/1 tray format • Exterior made of AISI 304 stainless steel or white coated steel • Rear panel in stainless steel (top and bottom in treated steel) • Interior fully made of AISI 304 18/10 stainless steel • Access via door (optional small doors available) • Self-closing door, with 90° open position hold • Key lock • LED lighting, automatic when opening the door and the upper small door • Standard stainless steel feet with 360° weld, adjustable from 149 mm to 209 mm • Insulation with injected polyurethane foam, 75 mm thick (except sides and door – 60 mm thick, foam density: 42 kg/m³), CFC, HFC, and HCFC-free • Electronic controller with digital display • High and low temperature alarms • Automatic defrost, hot gas defrost for low-temperature models • Hermetic monobloc air-cooled refrigeration unit (for 43°C ambient) • Built-in ventilated evaporator with anti-corrosion treatment

MONOBLOC GN 2/1 SPECIAL MODELS

Bi-temperature cabinets
​

  • 2 independant compartments

  • 2 x 300L

  • 1 compartment 0°C / +10°C

  • 1 compartment -18°C / -25°C

Mini cabinets on casters
​

  • Low-height cabinet (1990 mm)

  • On heavy-duty casters

  • Available in positive or negative version

  • Simplifies installation

Mini
BTSP 301.png
GSP 651.png

Special Fish cabinets

​
​

  • Drawers and drawer supports easily removable, facilitating cleaning

  • Diamond-patterned base with drain for water runoff

  • Stainless steel drawers with rear drainage

  • Temperature from -2°C to +10°C for fish compartments
